Kubernetes 1.22 - What's new? - New features and deprecations

Kubernetes 1.22 is about to be released, and it comes packed with novelties! Where do we begin?

This release brings 56 enhancements, an increase from 50 in Kubernetes 1.21 and 43 in Kubernetes 1.20. Of those 56 enhancements, 13 are graduating to Stable, a whopping 24 are existing features that keep improving, and 16 are completely new.

It’s great to see so many new features focusing on security, like the replacement for the Pod Security Policies, a rootless mode, and enabling Seccomp by default.

Also, watch out for all the deprecations and removals in this version!

There is plenty to talk about, so let’s get started with what’s new in Kubernetes 1.22.

Kubernetes 1.22 – Editor’s pick:

These are the features that look most exciting to us in this release (ymmv):

#2579 Pod Security Policy replacement

After being deprecated in Kubernetes 1.21, we knew a replacement for Pod Security Policies was on the way, but we didn’t know what it would look like. Now, we are happy to learn that it will be an Admission Controller, reusing part of the existing infrastructure.

Alvaro Iradier – Software Engineer at Sysdig

#2033 Rootless mode containers

Not running containers as root is the No. 1 container security best practice. It’s reassuring that this measure is being taken to the extreme, allowing us to run the entire Kubernetes stack in the user space. This is really gonna make Kubernetes more secure.

Alejandro Villanueva – Product Analyst at Sysdig

#2413 Seccomp by default

If one thing is clear after this Kubernetes release, it’s the shift to security first. Adding this extra layer of security by default will render many potential exploits pointless. Steps like this will absolutely change how people see Kubernetes.

Víctor Jiménez – Content Engineering Manager at Sysdig

#2400 Node swap support

One of those tiny details we like to see on every Kubernetes release, it won’t make headlines, but will make lives much easier. Swap was a given for every developer. By being supported, there’s one thing less to worry about when using Kubernetes.

Michele Zuccala – Director of Open Source Engineering at Sysdig

#2254 #2570 Cgroupsv2

Same as with swap, it’s great to see support for more native Linux features. In this case, Cgroupsv2 is enabling more options for Memory QoS, which (in Kubernetes 1.22) will help avoid performance throttling of workloads running in Kubernetes.

David de Torres – Manager of engineer at Sysdig

Deprecations

Beta API and feature removals

As Kat Cosgrove warned us, a few beta APIs and features have been removed in Kubernetes 1.22, including:

Ingress
CustomResourceDefinition
ValidatingWebhookConfiguration
MutatingWebhookConfiguration
CertificateSigningRequest

Not deprecated, but removed. That means that you won’t be able to re-enable them with a feature flag. If you are using them, you’ll have to migrate to their stable versions.

Check in the Kubernetes blog for the full list of removals and steps to migrate. And keep the deprecated API migration guide close for the future.

#1558 Streaming proxy redirects deprecation

Feature group: node

The StreamingProxyRedirects feature was initially developed to alleviate request overhead driven by the implementation of the Container Runtime Interface. The rationale was that by bypassing the kubelet, performance wouldn’t take a big hit.

However, with all requests centralized in the apiserver, those theoretical improvements weren’t as important. Also, some security concerns required the implementation of the ValidateProxyRedirects feature.

After being initially deprecated in 1.20, the feature gates have been disabled in 1.22. In Kubernetes 1.24, these features will be removed and the only way to configure container streaming will be by using the local redirect with Kubelet proxy approach. Check the full details in the KEP.

#536 Topology API

Feature group: network

As we mentioned in the last release, the #2433 Topology Aware Hints enhancement will replace the ServiceTopology feature gate that was introduced in Kubernetes 1.17.

#281 DynamicKubeletConfig deprecation

Feature group: node

After being in beta since Kubernetes 1.11, the Kubernetes team has decided to deprecate DynamicKubeletConfig instead of continuing its development.

Kubernetes 1.22 API

#555 Server-side Apply

Stage: Graduating to Stable
Feature group: api-machinery

This feature aims to move the logic away from kubectl apply to the apiserver, fixing most of the current workflow pitfalls and also making the operation accessible directly from the API (for example using curl), without strictly requiring kubectl or a Golang implementation.

Read more in our “Kubernetes 1.14 – What’s new?” article.

#1693 Warnings mechanism

Stage: Graduating to Stable
Feature group: api-machinery

From now on, the API server will include a warning header with deprecation information. This includes when an API was introduced, when it will be deprecated, and when it will be removed.

Read more in our “Kubernetes 1.19 – What’s new?” article.

#2161 Immutable label selectors for all namespaces

Stage: Graduating to Stable
Feature group: api-machinery

A new immutable label kubernetes.io/metadata.name has been added to all namespaces, where its value is the namespace name. This label can be used with any namespace selector, like in the previously mentioned NetworkPolicy objects.

Read more in our “Kubernetes 1.21 – What’s new?” article.

#1040 Priority and Fairness for API Server Requests

Stage: Graduating to Beta
Feature group: api-machinery

The APIPriorityAndFairness feature gate enables a new max-in-flight request handler in the API server. By defining different types of requests with FlowSchema objects and assigning them resources with RequestPriority objects, you can ensure the Kubernetes API server will be responsive for admin and maintenance tasks during high loads.

Read more in our “Kubernetes 1.18 – What’s new?” article.

Apps in Kubernetes 1.22

#2307 Job tracking without lingering Pods

Stage: Graduating to Alpha
Feature group: apps

With this enhancement, Jobs will be able to remove completed pods earlier, freeing resources in the cluster.

The current Job controller tracks completed Jobs by keeping Pods in a lingering state after they finish. Only when the Job is finished are the Pods removed, and the resources freed.

With the new approach, the Job controller will keep track of the completed jobs while allowing the completed Pods to be removed.

Check the KEP to learn the implementation details.

#2599 Add minReadySeconds to Statefulsets

Stage: Graduating to Alpha
Feature group: apps

This enhancement brings to StatefulSets the optional minReadySeconds field that is already available on Deployments, DaemonSets, ReplicasSets, and Replication Controllers.

If declared, a newly created Pod won’t be considered available until their containers stay ready without crashing for the specified number of seconds.

#19 CronJobs

Stage: Graduating to Stable
Feature group: apps

Introduced in Kubernetes 1.4 and in beta since 1.8, CronJobs are finally on the road to becoming Stable.

CronJobs runs periodic tasks in a Kubernetes cluster, similar to cron on UNIX-like systems.

Read more in our “Kubernetes 1.20 – What’s new?” article.

#85 PodDisruptionBudget eviction

Stage: Graduating to Stable
Feature group: apps

Introduced in Kubernetes 1.4 and in beta since 1.5, PodDisruptionBudget finally graduates to Stable.

With this API, you can define a minAvailable number of replicas for a Pod. If you try to voluntarily disrupt a Pod in a way that violates minAvailable value, it won’t be deleted.

While in Kubernetes 1.21 we saw the graduation of PodDisruptionBudget to GA, in Kubernetes 1.22 we see the graduation of the Eviction subresource:

{
  "apiVersion": "policy/v1",
  "kind": "Eviction",
  "metadata": {
    "name": "quux",
    "namespace": "default"
  }
}

#1591 Graduate DaemonSet maxSurge to beta

Stage: Graduating to Beta
Feature group: apps

When performing a rolling update, this enhancement allows specifying how many new Pods will be created to replace the old ones.

This is done via the optional spec.strategy.rollingUpdate.maxSurge field. By assigning an absolute number, you can tell the maximum number of Pods that can be created over the desired number of Pods. The value can also be a percentage of the desired Pods. The default value, to match the previous behavior, is 25 percent.

#2185 Graduate LogarithmicScaleDown to Beta

Stage: Graduating to Beta
Feature group: apps

When the LogarithmicScaleDown feature gate is enabled, a semi-random selection of Pods will be used to downscale ReplicaSets based on logarithmic bucketing of pod timestamps.

Read more in our “Kubernetes 1.21 – What’s new?” article.

#2255 Graduate PodDeletionCost to Beta

Stage: Graduating to Beta
Feature group: apps

You can now annotate Pods with controller.kubernetes.io/pod-deletion-cost=10, with 0 being the default value. When scaling down, a best effort will be made to remove Pods with a lower deletion cost.

Read more in our “Kubernetes 1.21 – What’s new?” article.

#2214 Indexed Job semantics in Job API

Stage: Graduating to Beta
Feature group: apps

Indexed jobs were introduced in Kubernetes 1.21 to make it easier to schedule highly parallelizable Jobs.

This enhancement adds completion indexes into the Pods of a Job with fixed completion count, to support running embarrassingly parallel programs.

This way, it is possible to pass the job index to the Pods via environment variables, or even create indexed jobs where pods can address each other by a hostname built from the index:

[...]
    spec:
      subdomain: my-job-svc
      containers:
      - name: task
        image: registry.example.com/processing-image
        command: ["./process",  "--index", "$JOB_COMPLETION_INDEX", "--hosts-pattern", "my-job-{{.id}}.my-job-svc"]

#2232 add suspend field to Jobs API

Stage: Graduating to Beta
Feature group: apps

Since Kubernetes 1.21, Jobs can be temporarily suspended by setting the .spec.suspend field of the job to true, and resumed later by setting it back to false.

Kubernetes 1.22 Authentication

#2579 Pod Security Policy replacement

Stage: Graduating to Alpha
Feature group: auth

A new PodSecurity admission controller is available to replace the Pod Security Policies deprecated in Kubernetes 1.21.

This new admission controller will be able to enforce Pod Security Standards by namespace. The enforcement can be done at three levels:

enforce: Policy violations will cause the pod to be rejected.
audit: Policy violations will trigger the addition of an audit annotation, but are otherwise allowed.
warn: Policy violations will trigger a user-facing warning, but are otherwise allowed.

It’ll be possible to configure this via the AdmissionConfiguration file:

apiVersion: apiserver.config.k8s.io/v1
kind: AdmissionConfiguration
plugins:
- name: PodSecurity
  configuration:
    defaults:  # Defaults applied when a mode label is not set.
      enforce:         <default enforce policy level>
      enforce-version: <default enforce policy version>
      audit:         <default audit policy level>
      audit-version: <default audit policy version>
      warn:          <default warn policy level>
      warn-version:  <default warn policy version>
    exemptions:
      usernames:         [ <array of authenticated usernames to exempt> ]
      runtimeClassNames: [ <array of runtime class names to exempt> ]
      namespaces:        [ <array of namespaces to exempt> ]

To learn more about the rationale behind this enhancement, and possible new developments, check the KEP.

#541 External client-go credential providers

Stage: Graduating to Stable
Feature group: auth

This enhancement allows Go clients to authenticate using external credential providers, like Key Management Systems (KMS), Trusted Platform Modules (TPM), or Hardware Security Modules (HSM).

Those devices are already used to authenticate against other services, are easier to rotate, and are more secure, as they don’t exist as files on the disk.

Initially introduced on Kubernetes 1.10, this feature concludes the work done in 1.20 and 1.21.

#542 Bound Service Account Token Volumes

Stage: Graduating to Stable
Feature group: auth

The current JSON Web Tokens (JWT) that workloads use to authenticate against the API have some security issues. This enhancement comprises the work to create a more secure API for JWT.

Read more in our “Kubernetes 1.20 – What’s new?” article.

#2784 CSR Duration

Stage: Graduating to Beta
Feature group: auth

Up until now, clients of the Certificates API weren’t able to request a specific duration for an issued certificate.

This duration defaulted to one year for every new certificate, which may be too long for some use cases.

A new ExpirationSeconds field has been added to CertificateSigningRequestSpec, which accepts a minimum value of 600 seconds (10 minutes).

Network in Kubernetes 1.22

#1669 kube-proxy handling terminating endpoints

Stage: Graduating to Alpha
Feature group: network

This enhancement approaches the edge case where Services with externalTrafficPolicy=Local will drop all traffic from a load balancer if the number of endpoints changes to 0. This behavior makes zero downtime rolling updates impossible for such services.

The implemented solution is to send all external traffic on the affected nodes to both ready and not ready terminating endpoints (preferring the ready ones).

To learn more about this edge case and the implementation details, check the KEP.

#2595 Expanded DNS configuration

Stage: Graduating to Alpha
Feature group: network

With this enhancement, Kubernetes allows more DNS search paths, and a longer list of DNS search paths, to keep up with recent DNS resolvers.

After enabling the MaxDNSSearchPathsExpanded feature gate, two DNS configuration limits are changed:

MaxDNSSearchPaths jumps from 6 to 32.
MaxDNSSearchListChars increases from 256 to 2048.

#752 EndpointSlice API

Stage: Graduating to Stable
Feature group: network

The new EndpointSlice API will split endpoints into several Endpoint Slice resources. This solves many problems in the current API that are related to big Endpoints objects. This new API is also designed to support other future features, like multiple IPs per pod.

Noteworthy in Kubernetes 1.22 is that if an Endpoints resource has more than 1000 endpoints, the cluster annotates them with endpoints.kubernetes.io/over-capacity: truncated, where before it was annotated with endpoints.kubernetes.io/over-capacity: warning.

Read more in our “Kubernetes 1.20 – What’s new?” article.

#1507 AppProtocol field in Services and Endpoints

Stage: Graduating to Stable
Feature group: network

After being stable since 1.20, the ServiceAppProtocol feature gate has now been removed.

Read more in our “Kubernetes 1.18 – What’s new?” article.

#1864 Service Disabling LB Node Ports

Stage: Graduating to Beta
Feature group: network

Some implementations of the LoadBalancer API do not consume the node ports automatically allocated by Kubernetes, like MetalLB or kube-router. However, the API requires a port to be defined and allocated, even if it’s not being used.

When the field allocateLoadBalancerNodePort in Service.Spec is set to false, it will stop allocating new node ports.

Read more in our “Kubernetes 1.20 – What’s new?” article.

#1959 Service LoadBalancer Class

Stage: Graduating to Beta
Feature group: network

This enhancement allows you to leverage multiple Service Type=LoadBalancer implementations in a cluster.

Read more in our “Kubernetes 1.21 – What’s new?” article.

#2079 Network Policy EndPort

Stage: Graduating to Beta
Feature group: network

This enhancement will allow you to define all ports in a NetworkPolicy as a range:

spec:
  egress:
  - ports:
    - protocol: TCP
      port: 32000
      endPort: 32768

Read more in our “Kubernetes 1.21 – What’s new?” article.

#2086 Service InternalTrafficPolicy

Stage: Graduating to Beta
Feature group: network

You can now set the spec.trafficPolicy field on Service objects to optimize your cluster traffic:

With Cluster, the routing will behave as usual.
When set to Topology, it will use the topology-aware routing.
With PreferLocal, it will redirect traffic to services on the same node.
With Local, it will only send traffic to services on the same node.

Read more in our “Kubernetes 1.21 – What’s new?” article.

#2365 Namespace Scoped Ingress Class Parameters

Stage: Graduating to Beta
Feature group: network

With this enhancement, you can now specify parameters for an IngressClass with a Namespace scope.

Read more in our “Kubernetes 1.21 – What’s new?” article.
